BM1383AGLV
氣壓感測器IC

BM1383AGLV是壓電電阻式氣壓感測器。在IC內部進行MEMS的溫度補償處理,可輕鬆獲取氣壓資訊。

Data Sheet 購買 *
* 本產品是標準級的產品。
本產品不建議使用的車載設備。

Product Detail


料號 | BM1383AGLV-ZE2
狀態 | 推薦品
封裝 | CLGA12V025M
單位數量 | 3000
最小包裝數量 | 3000
包裝形式 | Taping
RoHS | Yes

規格:

Grade

Standard

Sensor Type

Pressure Sensor Ics

Vcc(Min.)[V]

1.7

Vcc(Max.)[V]

3.6

Pressure Range [hPa]

300 to 1100

Relative Pressure Accuracy (Typ.) [hPa]

±0.12

Absolute Pressure Accuracy (Typ.) [hPa]

±1

Current Consumption (Typ.) [uA]

5.0

Operating Temperature (Min.)[°C]

-40

Operating Temperature (Max.)[°C]

85

功能:

  • Piezo-resistive pressure sensor.
  • Pressure range is from 300hPa to 1100hPa.
  • Built-in temperature compensation function.
  • I²C interface.
  • Small package.

Evaluation
Board


    • Evaluation Board
    • BM1383AGLV-EVK-001
    • BM1383AGLV-EVK-001 is an evaluation board for BM1383AGLV, which is a ROHM Pressure Sensor.

  • User's Guide Buy
    • Sensor Medal
    • SensorMedal-EVK-002
    • SensorMedal-EVK-002 is a sensor evaluation kit that uses the wireless communication function by BLE equipped with 6 sensors.

  • Buy Detail
    • Sensor Shield
    • SensorShield-EVK-003
    • SensorShield-EVK-003 is a Kit, which are included the 8 kinds of Sensor and Shield-EVK-001 which connects Arduino and ROHM Sensor Boards.

  • User's Guide Buy Detail
    • SPRESENSE Sensor EVK
    • SPRESENSE-BLE-EVK-701
    • In addition to the high-resolution audio codec and GPS receiver functions provided by the Spresense board computer for IoT supplied by Sony Semiconductor Solutions Corp., the Sensor Add-On Board (SPRESENSE-SENSOR-EVK-701) and Bluetooth® LE Add-On Board (SPRESENSE-BLE-EVK-701) add sensor capability and Bluetooth® LE communication functionality that contributes to the development and evaluation of advanced IoT devices.

  • User's Guide Buy Detail
    • SPRESENSE Sensor EVK
    • SPRESENSE-SENSOR-EVK-701
    • In addition to the high-resolution audio codec and GPS receiver functions provided by the Spresense board computer for IoT supplied by Sony Semiconductor Solutions Corp., the Sensor Add-On Board (SPRESENSE-SENSOR-EVK-701) and Bluetooth® LE Add-On Board (SPRESENSE-BLE-EVK-701) add sensor capability and Bluetooth® LE communication functionality that contributes to the development and evaluation of advanced IoT devices.

  • User's Guide Buy Detail
