AW2K21 (新產品)
30V 20A, Dual Nch+Nch, WLCSP2020, Power MOSFET
AW2K21 (新產品)
30V 20A, Dual Nch+Nch, WLCSP2020, Power MOSFET
AW2K21 is a power MOSFET with low on-resistance and High power small mold package, suitable for USB VBUS Protection, Battery Protection, and Load Switch.
Product Detail
規格:
Package Code
WLCSP2020
Number of terminal
22
Polarity
Nch+Nch
Drain-Source Voltage VDSS[V]
30
Drain Current ID[A]
20
RDS(on)[Ω] VGS=10V(Typ)
0.0015
RDS(on)[Ω] VGS=Drive (Typ)
0.002
Total gate charge Qg[nC]
29
Power Dissipation (PD)[W]
1.6
Drive Voltage[V]
5
Mounting Style
Surface mount
Storage Temperature (Min)[℃]
-55
Storage Temperature (Max)[℃]
150
Package Size [mm]
2.0x2.0 (t=0.58)
功能:
- Nch Common Source MOSFETs
- Low on - resistance.
- High Power small Package.
- Pb-free lead plating ; RoHS compliant.
- Halogen Free.
- WLCSP (Wafer level chip size package)
- Backside Coating
