BD14210G-LA
電流檢測放大器
BD14210G-LA
電流檢測放大器
BD14210G-LA是一款電流檢測放大器IC。該產品是能夠保證向工業設備市場長期供應的產品，而且是非常適用於這些應用領域的產品。該產品通過2.7V〜5.5V的單電源供電，支持-0.2V〜+26V的寬範圍共模電壓，輸出模擬電壓。檢測放大器的增益為20V/V。通過增益匹配電阻將增益誤差降至更低，從而具有低失調的特點。輸入電流低至1µA(Typ)，無需誤差調整。
該產品內置電流檢測放大器(CSA)，可提供30A電流檢測的參考設計。
Product Detail
規格:
Sensor Type
Current Sensor
Supply Voltage (Min.)[V]
2.7
Supply Voltage (Max.)[V]
5.5
Operating Current (Typ.)[mA]
0.17
Common Mode Voltage (Min.)[V]
-0.2
Common Mode Voltage (Max.)[V]
26
Gain (Typ.)[V]
20
Gain Accuracy (Max.)[%]
±1
Operating Temperature (Min.)[°C]
-40
Operating Temperature (Max.)[°C]
125
Package Size [mm]
2.9x2.8 (t=1.25)
功能:
- Long Time Support Product for Industrial Applications.
- Wide Common Mode Voltage Range
- High Accuracy
- Low Offset Voltage
- Low Input Bias Current
Supporting Information
背景
近年來，越來越多的應用產品需要具備電流檢測功能。例如，若要改善馬達效率和檢測異常狀況，就需要提高電流檢測精度，同時還希望能縮小安裝面積。在傳統結構（運算放大器+Discrete元件）中，存在著元件精度波動和因溫度特性導致電流檢測精度下降、難以縮小安裝面積等課題。為了解決上述市場課題，ROHM利用長年累積的類比技術優勢，研發出更節省空間且能高精度檢測電流的產品「BD1421x-LA系列」。
概要
將「BD14210G-LA」匯集週邊電路、並連接分流電阻後，即可進行電流檢測。與傳統結構（運算放大器+ Discrete元件）相比，「BD14210G-LA」將元件數量從11個減少為3個，安裝面積可減少約46%（封裝：SSOP6）。另外，更在整體溫度範圍（－40℃～＋125℃）內實現了±1%高精度電流檢測。不僅如此，透過改善內部電路，即使在外部安裝了雜訊對策用RC濾波電路的情況下，電流檢測精度也不會受到影響，將有助減少應用設計工時。可支援的輸入電壓範圍也更廣（－0.2V～＋26.0V），非常適用於12V和24V電源應用的電流檢測。
應用範例
・工控設備：無線基地台、PLC、逆變器、充電器等
・家電：空氣清淨機、冰箱等
Reference Design / Application Evaluation Kit
-
- Reference Design - REFSENS003
- 30A Current Sensing with current sense Amplifier (CSA)
REFSENSE003 is a reference design with a current sense amplifier: BD14210G-LA and a shunt resistor: LTR50UZPFU, which can be considered for current measurement using a shunt resistor. Current measurement circuits are used in various devices for high-side/low-side current sense, overcurrent sense, and current control of motors. The reference designs of shunt resistors and current-sense amplifiers presented on this website can be used for various current measurements as a solution that offers both high accuracy and small area. Design data and reference boards are available for purchase. Please make use of them to reduce your design person-hours.
- Built-in 1ch current sense amplifier BD14210G-LA/shunt resistor LTR50.
- Achieves current sense accuracy of 1%
- Supports current sense up to 30A
- Connectable with AD converter BU79100G-LA-EVK-001
-
