RB550ASA-30FH
車電用，低VF，30V，500mA，DFN1006-2W，蕭特基二極體
RB550ASA-30FH
車電用，低VF，30V，500mA，DFN1006-2W，蕭特基二極體
Quick Download
Description
RB550ASA-30FH為低VF、高可靠性蕭特基二極體，適用於一般整流。是一款車用高可靠性產品。
Product Detail
Specifications
Configuration
Single
Package Code
SOD-882 (DFN1006-2W)
Mounting Style
Surface mount
Number of terminal
2
VRM[V]
30
Reverse Voltage VR[V]
30
Average Rectified Forward Current IO[A]
0.5
IFSM[A]
1
Forward Voltage VF(Max.)[V]
0.59
IF @ Forward Voltage [A]
0.5
Reverse Current IR(Max.)[mA]
0.035
VR @ Reverse Current[V]
30
Tj[℃]
150
Storage Temperature (Min.)[°C]
-55
Storage Temperature (Max.)[°C]
150
Package Size [mm]
1.0x0.6 (t=0.4)
Common Standard
AEC-Q101 (Automotive Grade)
Features
- 高可靠性
- 小型電源模塑類型 (DFN1006-2W)
- 側邊可濕潤凸緣，可自動光學
焊點檢測 (AOI)鍍錫100%可焊接
側邊焊盤保證最小125um - 低VF
